5-bolt Ram 1500 rims and tires

The Ram 1500 from 2011 to 2018, and the Ram 1500 Classic from 2019 to 2024, use a 5x139.7 bolt pattern (also written 5x5.5") with a 77.8 mm centre bore and a conical lug seat. The redesigned 2019+ Ram 1500 is 6-bolt, so count the lug nuts on one wheel: five means this page, six means 6-bolt Ram 1500.

Factory sizes

Ram 1500, 2011 to 2018: wheels 17x7, 17x8, 20x8, 20x9 and 22x9 at +18 to +25 mm offset, with 265/70R17, 275/60R20 and 285/45R22 tires. Ram 1500 Classic, 2019 to 2024: wheels 17x7, 20x8 and 20x9 at +19 to +25 mm, with 265/70R17 and 275/60R20 tires.

Tell us your year, make, model and trim, plus any lift or levelling kit, and we check bolt pattern, offset, width, tire size, load rating and TPMS compatibility before you pay. Ram 1500 bolt pattern guide

In Saskatoon, pick it up or have it installed at our shop at #6 318 105th Street East. Out of town, we ship across Canada and give you the freight cost before you pay.
